Whiteness & chromaticity Tester 61-PPT100

Sample (size) length : Diameter ≥30 mm, Thickness ≤ 40 mm

Measurement mode : Diffuse reflection factor Rx, Ry, Rz, stimulus value Y10, X10, Z10, chromaticity coordinates x10, y10, z10; lightness L *, chroma a * b *, chroma C * ab, hue angle h * ab, dominant wavelength λd, excitement purity Pe, color difference ΔE * ab, lightness difference ΔL *, chroma difference ΔC * ab, hue difference ΔH * ab, Hunter system L , A, b

★ ★ ★ ★ ★

Whiteness Meter 61-PPT101

Sample (size) length : Diameter ≥30 mm, Thickness ≤ 40 mm

System : D/0 lighting geometrical viewing conditions, diffuser diameter (d) 150mm, testing hole diameter 30mm

★ ★ ★ ★ ★

Tensile stifness tester 61-PPT102

Sample (size) length : 38×70 mm

Measuring range : (1-500) mN.m (divided into 7 small ranges)

★ ★ ★ ★ ★

Automatic Tensile tester Horizontal 61-PPT103

Sample (size) length : 90 to 200 mm

Sample width : 15 mm, 25 mm, 50mm

★ ★ ★ ★ ★

Tensile horizontal tester 61-PPT104

Sample (size) length : 180 mm (180, 150, 100, 90, 50 mm adjustable)

Sample width : 15 mm

★ ★ ★ ★ ★

Vertical tensile tester 61-PPT105

Sample (size) length : 0 to 200 mm adjustable

Sample width : 15 mm

★ ★ ★ ★ ★

Pulp beating freeness tester 61-PPT106

Measurement range : 0 to 100° SR

Sealed testing speed : 100 ± 10 mm/s

★ ★ ★ ★ ★

Water absorption tester (KLEMN type) 61-PPT107

Measurement range : 0 to 200 mm

Specimen size : 15×250 mm

★ ★ ★ ★ ★

Cobb Water absorption tester 61-PPT108

Metal Cylinder inner area : (100 ± 0.2) cm2

Metal Cylinder height : 50 mm

★ ★ ★ ★ ★

Coefficient of friction tester 61-PPT110

Measurement range : 0.01 to 10 N

Slider weight : 200 g

★ ★ ★ ★ ★

Electronic bending stiffness tester 61-PPT111

Testing speed : 200° ± 20° / min

Test range : 1 to 10000 mN

★ ★ ★ ★ ★

Paper and cardboard thickness meter 61-PPT112

Measuring range : 0 to 4 mm

Accuracy : 0.01 or 0.001 mm

★ ★ ★ ★ ★

Corrugated cardboard thickness meter 61-PPT113

Measuring range : 0 to 20 mm

Accuracy : 0.01 mm

★ ★ ★ ★ ★

Ink rubber tester 61-PPT114

Sample size (L*B) : 230×50 mm (can join short samples together)

Rub pressure : 20 ± 0.2 N

★ ★ ★ ★ ★

Standard strip cutter 61-PPT115

Sample width : 15 mm

Sample maximum length : 300 mm

★ ★ ★ ★ ★

Softness tester 61-PPT116

Measuring range : 10 to 1000 mN

Division value : 1 mN

★ ★ ★ ★ ★

Compression tester 61-PPT117

Measuring range : 0.1 to 10 kN

Indication error : < ± 1%

★ ★ ★ ★ ★

Compression tester 61-PPT118

Measuring range : 1 to 50 kN

Indication error : < ± 1%

★ ★ ★ ★ ★

Air permeability tester 61-PPT119

Measuring range : 0 to 1000 ml/min

Test area : 10 ± 0.02 cm2

★ ★ ★ ★ ★

Internal Ply bond Tester 61-PPT120

Capacity : A: 20 to 500 J/m2 B: 500 to 1000 J/m2

Impact angle : 90°

★ ★ ★ ★ ★

Puncture strength tester 61-PPT121

Measuring range : A (1 to 6) J indicating error ± 0.05 J
B (1 to 12) J indicating error ± 0.05 J
C (1 to 24) J indicating error ± 0.05 J
D (1 to 48) J indicating error ± 0.05 J
The indicating errors w.r.t measurement range of 20 to 80 %
